GO Actuator Mirror Mounts
Two or three PRECIBEO GO Actuators enables 2- or 3-axis Mirror Mounts.
GO Linear Actuator
The linear actuator offers a footprint of 67×28 mm, a travel range of 9 mm and 10 N operating lift force.
All products in the modular PRECIBEO GO system are compatible and are easily combined into multi-axis systems offering smooth continuous motion, fast step and settling times, and self-locking at rest.
| Positioning | GO Linear Actuator |
|---|---|
| Travel (X) | 9 mm |
| Position Sensor | Optical Encoder |
| Sensor Resolution | 2 nm |
| Minimum Incremental Motion | 2 nm |
| Bidirectional Repeatability | ± 200nm (typ. @ full travel) |
| Motion | GO Linear Actuator |
| Maximum Operating Force (Push/Pull) | 10 N (min.) |
| Holding Force (When Power Is Off) | 10 N (min.) |
| Maximum Speed (At No Load) | 8 mm/s |
| Maximum Speed (At Maximum Operating Force) | 1 mm/s (min.) |
| Drive Type | GO Linear Actuator |
| Motor Type | Piezo Drive |
| Mechanical | GO Linear Actuator |
| Mechanical Interface | 9.5 mm clamping shank or M9 mounting thread |
| Size | 67x28x14 mm |
| Miscellaneous | GO Linear Actuator |
| Cable | 2 m cable (±5%) with ix Industrial™ connector |
| Material | Piston: Stainless Steel |
